C-CA55 SERIES
C-CA100 SERIES
C-CA100 SERIES
The C-CA55 Series is offered in several variations, providing proven and effective solutions for optimum metering and delivery of either LPG vapor or Natural Gas. The standard model can he mounted in either an updraft, downdraft, or side draft orientation, supplying either LPG or Natural Gas to engines up to 73 hp (54.0 kW), with a flow r
The C-CA55 Series is offered in several variations, providing proven and effective solutions for optimum metering and delivery of either LPG vapor or Natural Gas. The standard model can he mounted in either an updraft, downdraft, or side draft orientation, supplying either LPG or Natural Gas to engines up to 73 hp (54.0 kW), with a flow rate of 118 CFM (55.7 L/s). Various SAE flanges and air horn sizes are available.
C-CA100 SERIES
C-CA100 SERIES
C-CA100 SERIES
The C-CA100 Series is a single diaphragm air-gas valve carburetor/mixer. If offers a 90 degree air inlet to provide low overhead clearance, and is available with several air horn and throttle body options. This unit is available for LPG Vapor and Natural Gas applications with airflow requirements up to 197 CFM (93 L/s). The model C-CA100
The C-CA100 Series is a single diaphragm air-gas valve carburetor/mixer. If offers a 90 degree air inlet to provide low overhead clearance, and is available with several air horn and throttle body options. This unit is available for LPG Vapor and Natural Gas applications with airflow requirements up to 197 CFM (93 L/s). The model C-CA100 is also available with 'FB' designation.
The 100 mixer provides a convenient 1/8 NPT balance port and two separate air valve vacuum ports. Additional low speed, idle mixture control can be obtained to lean air/fuel mixtures through the use of optional shims.
C-CA125 SERIES
C-CA100 SERIES
C-CA125 SERIES
The C-CA125 Series is a single-diaphragm air valve carburetor/mixer for applications requiring airflow up to 235 CFM (111 L/s). It offers a down draft air inlet that can be used for remote air filtration or open-element type air filters. This unit is available for LPG Vapor and Natural Gas Vapor applications.
Two separate air valve vacuum
The C-CA125 Series is a single-diaphragm air valve carburetor/mixer for applications requiring airflow up to 235 CFM (111 L/s). It offers a down draft air inlet that can be used for remote air filtration or open-element type air filters. This unit is available for LPG Vapor and Natural Gas Vapor applications.
Two separate air valve vacuum supplies are available with this mixer. Additional low speed mixture control can be obtained to lean air/fuel mixtures with optional shims.
C-CA200 SERIES
C-CA200 SERIES
C-CA125 SERIES
The C-CA200 Series is a single diaphragm air-valve carburetor/mixer. It offers a 90° air inlet to provide low overhead clearance, and is available with several air horn and throttle valve options. This unit is available for LPG Vapor or Natural Gas for applications with airflow requirements up to 345 CFM (162.8 L/s). All DG model mixers r
The C-CA200 Series is a single diaphragm air-valve carburetor/mixer. It offers a 90° air inlet to provide low overhead clearance, and is available with several air horn and throttle valve options. This unit is available for LPG Vapor or Natural Gas for applications with airflow requirements up to 345 CFM (162.8 L/s). All DG model mixers reduce airflow by 30%.
The C-CA200 is also available for feedback applications with the ’FB’ designation. The C-CA200 provides a convenient 1/8” balance port at the air inlet. Additional low speed idle mixture control can be obtained to lean air/fuel mixtures through the use of optional shims.
C-CA225 SERIES
C-CA200 SERIES
C-CA225 SERIES
The C-CA225 Series is a single-diaphragm air valve carburetor/mixer. It offers a down-draft air inlet that can be used for remote air filtration or open-element type air filters. This unit is available for LPG Vapor or Natural Gas applications with airflow requirements up to 380 CFM (179.3 L/s).
The C-CA225 is also available for feedback a
The C-CA225 Series is a single-diaphragm air valve carburetor/mixer. It offers a down-draft air inlet that can be used for remote air filtration or open-element type air filters. This unit is available for LPG Vapor or Natural Gas applications with airflow requirements up to 380 CFM (179.3 L/s).
The C-CA225 is also available for feedback applications with the ‘FB’ designation.
Two separate air valve vacuum supplies are available with this mixer. Additional low speed mixture control can be obtained to lean air/fuel mixtures with optional ring spacers/shims.
C-CA300 SERIES
C-CA200 SERIES
C-CA225 SERIES
The C-CA300 Series is a single-diaphragm air valve for applications. It offers a down-draft air inlet that can be used for remote air filtration or open-element type air filters. This unit is available for LPG Vapor and Natural Gas applications with airflow requirements up to 348 CFM (164 L/s) or 432 CFM (204 L/s) depending on the part nu
The C-CA300 Series is a single-diaphragm air valve for applications. It offers a down-draft air inlet that can be used for remote air filtration or open-element type air filters. This unit is available for LPG Vapor and Natural Gas applications with airflow requirements up to 348 CFM (164 L/s) or 432 CFM (204 L/s) depending on the part number. The C-300A has numerous adapters to allow the installer to fit the C-300A into most under hood vehicle applications.
